Taramps BASS3K 1OHM
Taramps BASS3K 1OHM
Regular price
$369.99 USD
Regular price
Sale price
$369.99 USD
Unit price
per
Couldn't load pickup availability
TECHNICAL INFORMATION
| OPERATION CLASS | Class D |
|---|---|
| MINIMUM OUTPUT IMPEDANCE | 1 Ohm |
| NUMBER OF CHANNELS | 01 |
| MAXIMUM POWER | @ 14.4 VDC - 1 Ohm: 3000 Watts RMS @ 14.4 VDC - 2 Ohms: 1920 Watts RMS |
| INPUT SENSITIVITY | 220mV |
| SIGNAL TO NOISE RATIO | > 95dB |
| FREQUENCY RESPONSE | 8Hz ~ 250Hz (-3dB) |
| CROSSOVER HIGH PASS (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
| CROSSOVER LOW PASS (LPF) | 60Hz ~ 250Hz (-12dB/8ª) Variable |
| BASS BOOST | Freq.: 35Hz ~ 60Hz / Boost: 0 ~ +10dB |
| EFFICIENCY | 80% |
| INPUT IMPEDANCE | 15K Ohms |
| OUTPUT IMPEDANCE | 1 Ohm |
| PROTECTION SYSTEM | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
| MINIMUM SUPPLY VOLTAGE | 9 VDC |
| MAXIMUM SUPPLY VOLTAGE | 17 VDC |
| CONSUMPTION AT REST | 1.10A |
| MAXIMUM MUSIC CONSUMPTION | 130A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL | 260A |
| DIMENSIONS (WXHXD) | 9.41" x 2.87" x 8.58" (239 x 73 x 218mm) |
| WEIGHT | 6.51lb (2.96Kg) |
| EAN | 7898556844789 |
